Onkyo HT-R410 Service Manual

HT-R410
PRINTED CIRCUIT BOARD VIEW 1 FROM SOLDERING SIDE
Front panel section
Display circuit PC board ass'y
(NADIS-7403)
C
7512
D7505
JL7501A
JL7502A
1
R7581
R7582
S7611 S7612
S7613 S7621
S7622
S7623S7624
S7625
7
626
7
X7501
J7503 J7504
J7506
J7507
J7508
J7509
J7516
J7517
J7520
J7531
J7532
J7533
J7534
J7536
J7541
J7545
J7546 J7547
Y
DIGITAL
INPUT
SW
MODE
DIMMER DISPLAY
DVDVIDEO1VIDEO2
D
EO3
AUDIO
SELECTER
RL7501
J7550
J7551
HPR
HPE
HPL
GND
HPDET
2 2
22
2222
12
15
12
7
20
17
22
15
22
7
15
7
7
12
7
C7504
C7505
C7515
C7516
C
7517
D7501
D7507
L7504
L7505
R7526 R7527
R7646
R7631
R7641
R7642
R7643
R7644
R7645
-VP
HPMUT
SBMRST SBMCLK
SBMDO SBMDI
SBMLDY
HPDET
SYSIN
GND
FLAC FLAC
GND GND HPL HPE HPR
+5.6V
Soldering side
S7616 S7615
S7614
JL7501B
STANDBY
SPA SPB
NCSW-7404
25137404
0
2
2
2
R7613
R7614
R7615
Soldering side
Component side
U3
Standby switch PC board ass'y
(NASW-7404)
U4
P7501
P7501
JL7502B
J7572
J7573
J7571
E7501
NCETC-7405
25137405
0
R L
J7574
L7503
L7502
L7501
C7519
C7520
C7518
R L
Headphone terminal PC board ass'y
(NAETC-7405)
Soldering sideComponent side
A
1
2
3
4
5
BCD

Onkyo HT-R410 Specifications

Amplifier Section

Power Output Front L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Power Output Center Speaker	100 Watts min. RMS at 8 ohms, 20-20, 000 Hz, 0.08% THD
Power Output Surround L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Dynamic Power Output at 3 ohms	230 watts × 2
Dynamic Power Output at 4 ohms	170 watts × 2
Dynamic Power Output at 8 ohms	115 watts × 2

Input and Output Impedance

Digital Input Optical	0.5 Vp-p, 75 ohms
Digital Input Coaxial	0.5 Vp-p, 75 ohms
Line Input (CD, VIDEO 1, 2, 3, TAPE)	200 mV, 47 kohms
Multichannel Input (DVD FRONT L/C/R, SURR L/R)	200 mV, 47 kohms
Multichannel Input (SUBWOOFER)	36 mV, 47 kohms
Output Level Rec out (TAPE, VIDEO 1)	200 mV, 470 ohms
Output Level Pre out (SUBWOOFER)	1 V, 470 ohms

Tuner Section

FM Tuning Range	87.5-108.0 MHz (100 kHz steps)
FM Usable Sensitivity Mono	11.2 dBf, 1.0 µV (75 ohms, IHF)
FM Usable Sensitivity Stereo	17.2 dBf, 2.0 µV (75 ohms, IHF)
FM 50 dB Quieting Sensitivity Mono	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB Quieting Sensitivity Stereo	37.2 dBf, 20.0 µV (75 ohms)
FM Capture Ratio	2.0 dB
FM Image Rejection Ratio	40 dB
FM IF Rejection Ratio	90 dB
FM Signal-to-Noise Ratio Mono	76 dB, IHF
FM Signal-to-Noise Ratio Stereo	70 dB, IHF
FM Alternate Channel Attenuation	55 dB, IHF, ±400 kHz
FM Selectivity	50 dB (DIN)
FM AM Suppression Ratio	50 dB
FM Total Harmonic Distortion Mono	0.2%
FM Total Harmonic Distortion Stereo	0.3%
FM Frequency Response	30 Hz-15 kHz, ±1.0 dB
FM Stereo Separation at 1 kHz	45 dB
FM Stereo Separation at 100 Hz-10 kHz	30 dB
AM Tuning Range	530-1, 710 kHz (10 kHz steps)
AM Usable Sensitivity	30 µV
AM Image Rejection Ratio	40 dB
AM IF Rejection Ratio	40 dB
AM Signal-to-Noise Ratio	40 dB
AM Total Harmonic Distortion	0.7%

General Specifications

Power Supply	AC 120 V, 60 Hz
Power Consumption	4.7 A
Dimensions (W × H × D)	17-1/8” × 5-7/8” × 14-3/8”
Dimensions in mm (W × H × D)	435 × 150 × 365 mm
Weight	19.0 lbs., 8.6 kg
