HT-R410
A
1
2
3
4
5
BCD
WIRING VIEW
JL6952B
JL6951B
P911A
P912A
P913A
7
3
1
5
P6909
LSP
RSP
CSP
LSSP
RSSP
P996A
B+
+B1
B+
+B1
B+
+B1
+B1
JL9501B
P6072
JL7501B
JL7501A
JL7502A
P7501
JL7502B
NADIS-7403,Display ci
r
NASW-7404,
Standby switch
PC board ass'y
NAETC-7405,
Headphone
terminal PC
board ass'y
NAETC-7869,
Secondary terminal A
PC board ass'
y
NAETC-7870,Speaker
terminal PC board ass'y
NAAF-7875,
Power amplifier
PC board ass'y
NAPS-7876,
Terminal
PC board ass'y
U18
NAPS-7877,Primary circuit
PC board ass'y
NAPS-7878,
Secondary circuit
PC board ass'y
U9
U19
U17
T901
POWER
TRANS-
FORMER
NPT-1464D
U8
U2
U3
U4
U16
U10
JL7501A
P6801
JL6805B
JL6804B
P6800
JL6803B
P6931A
JL9501
P902
P901A
P909 P908
T902
AC-G
S902
S902
P917
P918
P911
P922
P923
AC-H
P931A
120V 220V
P921A
P921
P922A
P923A
P913
P912
P926
P925
AC-GAC-H
1234
578
56789
JL640
2B
P6931
JL6803A
JL6804A
P6011
P931
JL69
51A
NCAF-7875
+24V
CSRLD
FRLD
BRLD
JL6805A
P6301
JL640
2A
COM
TH1
+24V
+24V
TH1
L
RCLSRS
B-
B+
+B1
-B1
NF
P6004
B-
B+
+B1
-B1
NF
P6003
B-
B+
+B1
-B1
NF
P6002
B-
B+
+B1
-B1
NF
P6001
B+
+B1
-B1
NF
P6000
ID-ID+
R6040
P6080
BIAS
ID-ID+
R6043
P6083
ID-ID+
R6042
P6082
ID-ID+
R6041
P6081
ID-ID+
R6044
P6084
JL6952A
U21
NPT-1358
DG or D

Other manuals for Onkyo HT-R410

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo HT-R410 and is the answer not in the manual?

Onkyo HT-R410 Specifications

Amplifier Section IconAmplifier Section
Power Output Front L/R Speakers100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Power Output Center Speaker100 Watts min. RMS at 8 ohms, 20-20, 000 Hz, 0.08% THD
Power Output Surround L/R Speakers100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Dynamic Power Output at 3 ohms230 watts × 2
Dynamic Power Output at 4 ohms170 watts × 2
Dynamic Power Output at 8 ohms115 watts × 2
Input and Output Impedance IconInput and Output Impedance
Digital Input Optical0.5 Vp-p, 75 ohms
Digital Input Coaxial0.5 Vp-p, 75 ohms
Line Input (CD, VIDEO 1, 2, 3, TAPE)200 mV, 47 kohms
Multichannel Input (DVD FRONT L/C/R, SURR L/R)200 mV, 47 kohms
Multichannel Input (SUBWOOFER)36 mV, 47 kohms
Output Level Rec out (TAPE, VIDEO 1)200 mV, 470 ohms
Output Level Pre out (SUBWOOFER)1 V, 470 ohms
Tuner Section IconTuner Section
FM Tuning Range87.5-108.0 MHz (100 kHz steps)
FM Usable Sensitivity Mono11.2 dBf, 1.0 µV (75 ohms, IHF)
FM Usable Sensitivity Stereo17.2 dBf, 2.0 µV (75 ohms, IHF)
FM 50 dB Quieting Sensitivity Mono17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB Quieting Sensitivity Stereo37.2 dBf, 20.0 µV (75 ohms)
FM Capture Ratio2.0 dB
FM Image Rejection Ratio40 dB
FM IF Rejection Ratio90 dB
FM Signal-to-Noise Ratio Mono76 dB, IHF
FM Signal-to-Noise Ratio Stereo70 dB, IHF
FM Alternate Channel Attenuation55 dB, IHF, ±400 kHz
FM Selectivity50 dB (DIN)
FM AM Suppression Ratio50 dB
FM Total Harmonic Distortion Mono0.2%
FM Total Harmonic Distortion Stereo0.3%
FM Frequency Response30 Hz-15 kHz, ±1.0 dB
FM Stereo Separation at 1 kHz45 dB
FM Stereo Separation at 100 Hz-10 kHz30 dB
AM Tuning Range530-1, 710 kHz (10 kHz steps)
AM Usable Sensitivity30 µV
AM Image Rejection Ratio40 dB
AM IF Rejection Ratio40 dB
AM Signal-to-Noise Ratio40 dB
AM Total Harmonic Distortion0.7%
General Specifications IconGeneral Specifications
Power SupplyAC 120 V, 60 Hz
Power Consumption4.7 A
Dimensions (W × H × D)17-1/8” × 5-7/8” × 14-3/8”
Dimensions in mm (W × H × D)435 × 150 × 365 mm
Weight19.0 lbs., 8.6 kg
