Onkyo HT-R410 Service Manual

HT-R410
A
1
2
3
4
5
BCD
SCHEMATIC DIAGRAM 3 Driver section
Q5013Q5003
Q5043
Q5053
Q5014Q5004
Q5044
Q5054
Q5033
Q5034
R5013
56K
R5003
1K
R5023
330
R5063
1.2K
R5163
120
(1/4W)
R5133
18K
R5173
120
(1/4W)
R5033
56K
R5083
3.3K
R5113
1K
R5093
100K
R5053
4.7K
R5073
560
R5103
100K
R5183
10
(1/4W)
R5193
10
(1/4W)
R5043 2.2K
R5014
56K
R5004
1K
R5024
330
R5064
1.2K
R5164
120
(1/4W)
R5134
18K
R5174
120
(1/4W)
R5034
56K
R5084
3.3K
R5114
1K
R5094
100K
R5054
4.7K
R5074
560
R5104
100K
R5184
10
(1/4W)
R5194
10
(1/4W)
R5044
2.2K
C5013
22/16
C5043
100/16
C5053
47/50
C5113
10/100
C5103
10/100
C5023
10/50
C5014
22/16
C5044
100/16
C5054
47/50
C5114
10/100
C5104
10/100
C5024
10/50
C5003
101K
C5083
040D
C5093
101J
C5004
101K
C5084
040D
C5094
101J
P6003A
TO NAAF-7875
(SCH-4)
P6004A
TO NAAF-7875
(SCH-4)
D5003
MTZJ5.6B
D5004
MTZJ5.6B
[62.1V]
[-62.1V]
[60.7V]
[61.5V]
[-56.5V]
[-61.4V]
[-57.1V]
[1.0V]
[-60.6V]
[0V]
[-1V]
[62.1V]
[-62.1V]
[60.7V]
[61.5V]
[-56.5V]
[-61.4V]
[-57.1V]
[1.0V]
[-60.6V]
[0V]
[-1V]
SEMICONDUCTORS
NO. DESCRIPTION
Q5000-04,5010-14 KTC3200-BL OR 2SC1775A-E,F OR 2SC1845-E
Q5030-34 KTA1024-Y,O OR 2SA949-Y,O
Q5040-44 KTC3206-Y,O OR 2SC2229-Y,O
Q5050-54
KTC3200-BL,GR OR 2SC1775A-E,F OR 2SC1845-E,F
SR
SL
NAAF-7866
NF
-B1
+B1
B+
B-
NF
-B1
+B1
B+
B-
[-0.1V]
[-0.7V]
[-0.1V]
[-0.7V]

Onkyo HT-R410 Specifications

Amplifier Section

Power Output Front L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Power Output Center Speaker	100 Watts min. RMS at 8 ohms, 20-20, 000 Hz, 0.08% THD
Power Output Surround L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Dynamic Power Output at 3 ohms	230 watts × 2
Dynamic Power Output at 4 ohms	170 watts × 2
Dynamic Power Output at 8 ohms	115 watts × 2

Input and Output Impedance

Digital Input Optical	0.5 Vp-p, 75 ohms
Digital Input Coaxial	0.5 Vp-p, 75 ohms
Line Input (CD, VIDEO 1, 2, 3, TAPE)	200 mV, 47 kohms
Multichannel Input (DVD FRONT L/C/R, SURR L/R)	200 mV, 47 kohms
Multichannel Input (SUBWOOFER)	36 mV, 47 kohms
Output Level Rec out (TAPE, VIDEO 1)	200 mV, 470 ohms
Output Level Pre out (SUBWOOFER)	1 V, 470 ohms

Tuner Section

FM Tuning Range	87.5-108.0 MHz (100 kHz steps)
FM Usable Sensitivity Mono	11.2 dBf, 1.0 µV (75 ohms, IHF)
FM Usable Sensitivity Stereo	17.2 dBf, 2.0 µV (75 ohms, IHF)
FM 50 dB Quieting Sensitivity Mono	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB Quieting Sensitivity Stereo	37.2 dBf, 20.0 µV (75 ohms)
FM Capture Ratio	2.0 dB
FM Image Rejection Ratio	40 dB
FM IF Rejection Ratio	90 dB
FM Signal-to-Noise Ratio Mono	76 dB, IHF
FM Signal-to-Noise Ratio Stereo	70 dB, IHF
FM Alternate Channel Attenuation	55 dB, IHF, ±400 kHz
FM Selectivity	50 dB (DIN)
FM AM Suppression Ratio	50 dB
FM Total Harmonic Distortion Mono	0.2%
FM Total Harmonic Distortion Stereo	0.3%
FM Frequency Response	30 Hz-15 kHz, ±1.0 dB
FM Stereo Separation at 1 kHz	45 dB
FM Stereo Separation at 100 Hz-10 kHz	30 dB
AM Tuning Range	530-1, 710 kHz (10 kHz steps)
AM Usable Sensitivity	30 µV
AM Image Rejection Ratio	40 dB
AM IF Rejection Ratio	40 dB
AM Signal-to-Noise Ratio	40 dB
AM Total Harmonic Distortion	0.7%

General Specifications

Power Supply	AC 120 V, 60 Hz
Power Consumption	4.7 A
Dimensions (W × H × D)	17-1/8” × 5-7/8” × 14-3/8”
Dimensions in mm (W × H × D)	435 × 150 × 365 mm
Weight	19.0 lbs., 8.6 kg
