Onkyo HT-R410 Service Manual

HT-R410
SCHEMATIC DIAGRAM 4 Power amplifier section
P6011
TO NAAF-7866
(SCH-3)
JL6952A
TO NAPS-7879
(SCH-5)
JL6951A
TO NAPS-7879
(SCH-5)
F6901
8A-UL
F6902
8A-UL
RL6901
RL6902
D6903
RS603M
RBV602
D5SBA20
D6903,6904:
D6904
[0.1V]
[0.8V]
[-62.1V]
[-0.5V]
[0.5V]
[1.1V]
[-1.1V]
[-0.5V]
[1V]
[0.2V]
[-0.3V]
[-0.3V]
[62.1V]
[0V]
[0V]
[0.5V]
[-62.1V]
[-0.5V]
[0.5V]
[1.1V]
[-1.1V]
[-0.5V]
[1V]
[0.2V]
[-0.3V]
[-0.3V]
[62.1V]
[0V]
[0V]
[0.5V]
Q6901
Q6034
Q6074
Q6024
Q6014
Q6054
Q6033
Q6073
Q6023
Q6013
Q6053
R6902
1K
R6054
3.9K
R6084
2.2
(1/4W)
R6074
110
(1/4W)
R6234
8.2
(1W)
R6014
3.9K
R6004
5.6K
R6034
390
R6164
33K
R6094
2.2
(1/4W)
R6154
12K
R6144
22K
R6194
330K
R6174
47K
R6184
47K
R6053
3.9K
R6083
2.2
(1/4W)
R6073
110
(1/4W)
R6233
8.2
(1W)
R6013
3.9K
R6003
5.6K
R6033
390
R6163
33K
R6093
2.2
(1/4W)
R6153
12K
R6143
22K
R6193
330K
R6173
47K
R6183
47K
C6902
C6901
10000/71
C6044
47/50
C6043
47/50
C6906
104J
C6907
104J
C6904
C6905
334J
/100
C6234
473J
C6054
223J
C6233
473J
C6053
223J
R6044
1K
R6043
1K
R6104
0.22 X2
(2W)
R6103
0.22 X2
(2W)
D6906
D6014
D6004
D6013
D6003
P6004
TO NAAF-7866
(SCH-3)
P6003
TO NAAF-7866
(SCH-3)
TO NAAF-7866 TO NAAF-7866 TO NAAF-7866
P931
TO NAPS-7877
(SCH-5)
Q6044
Q6064
Q6043
Q6063
C6903
104J
C6708
223Z
P6906
P6084
ID+
ID-
P6083
ID+
ID-
NF
-B1 E
+B1
E
B+ E
B- E
E
E
E
E
E
NF
-B1
+B1
B+
B-
+13VS
+13VS
MPUGND
MPUGND
POWER
SEMICONDUCTORS
NO. DESCRIPTION
Q6010-6014 2SC1740S-R,S
Q6020-6024 2SC1740S-R,S
Q6030-6034 KTD2061-Y OR 2SC5171
Q6040-6044 KTB1369-Y OR 2SA1930
Q6050-6054 KTC5242-O,R OR MN130S-Y,P,O OR 2SC5242-O,R
Q6060-6064 KTA1962-O,R OR MP130S-Y,P,O OR 2SA1962-O,R
Q6070-6074 2SC2631-R,S
Q6601-6603,Q6901 KTC3199-GR,2SC1740S-R,S,2SC2458-GR
Q6701,6702 KTC3200-BL,GR OR 2SC1775A-E,F OR 2SC1845-E,F
Q6703 KTA1268-GR,BL OR 2SA992-E,F
Q6303
KTA1267-GR OR 2SA933S-R,S
SR
SL
NAAF-7875
10000/71
334J/100
A
1
2
3
4
5
BCD

Onkyo HT-R410 Specifications

Amplifier Section

Power Output Front L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Power Output Center Speaker	100 Watts min. RMS at 8 ohms, 20-20, 000 Hz, 0.08% THD
Power Output Surround L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Dynamic Power Output at 3 ohms	230 watts × 2
Dynamic Power Output at 4 ohms	170 watts × 2
Dynamic Power Output at 8 ohms	115 watts × 2

Input and Output Impedance

Digital Input Optical	0.5 Vp-p, 75 ohms
Digital Input Coaxial	0.5 Vp-p, 75 ohms
Line Input (CD, VIDEO 1, 2, 3, TAPE)	200 mV, 47 kohms
Multichannel Input (DVD FRONT L/C/R, SURR L/R)	200 mV, 47 kohms
Multichannel Input (SUBWOOFER)	36 mV, 47 kohms
Output Level Rec out (TAPE, VIDEO 1)	200 mV, 470 ohms
Output Level Pre out (SUBWOOFER)	1 V, 470 ohms

Tuner Section

FM Tuning Range	87.5-108.0 MHz (100 kHz steps)
FM Usable Sensitivity Mono	11.2 dBf, 1.0 µV (75 ohms, IHF)
FM Usable Sensitivity Stereo	17.2 dBf, 2.0 µV (75 ohms, IHF)
FM 50 dB Quieting Sensitivity Mono	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB Quieting Sensitivity Stereo	37.2 dBf, 20.0 µV (75 ohms)
FM Capture Ratio	2.0 dB
FM Image Rejection Ratio	40 dB
FM IF Rejection Ratio	90 dB
FM Signal-to-Noise Ratio Mono	76 dB, IHF
FM Signal-to-Noise Ratio Stereo	70 dB, IHF
FM Alternate Channel Attenuation	55 dB, IHF, ±400 kHz
FM Selectivity	50 dB (DIN)
FM AM Suppression Ratio	50 dB
FM Total Harmonic Distortion Mono	0.2%
FM Total Harmonic Distortion Stereo	0.3%
FM Frequency Response	30 Hz-15 kHz, ±1.0 dB
FM Stereo Separation at 1 kHz	45 dB
FM Stereo Separation at 100 Hz-10 kHz	30 dB
AM Tuning Range	530-1, 710 kHz (10 kHz steps)
AM Usable Sensitivity	30 µV
AM Image Rejection Ratio	40 dB
AM IF Rejection Ratio	40 dB
AM Signal-to-Noise Ratio	40 dB
AM Total Harmonic Distortion	0.7%

General Specifications

Power Supply	AC 120 V, 60 Hz
Power Consumption	4.7 A
Dimensions (W × H × D)	17-1/8” × 5-7/8” × 14-3/8”
Dimensions in mm (W × H × D)	435 × 150 × 365 mm
Weight	19.0 lbs., 8.6 kg
