Onkyo HT-R410 Service Manual

Pin No. Symbol I/O Description Pin No. Symbol I/O Description
1 VDD Power supply terminal. Connect to 5V. 41 P22 O Segment output terminal of P22.
2 VSS Ground terminal. 42 P21 O Segment output terminal of P21.
3 X1 Ceramic oscillator connection terminals for main system. 43 P20 O Segment output terminal of P20.
4 X2 Connect the 5MHz ceramic oscillator between #3 and #4. 44 P19 O Segment output terminal of P19.
5 IC/VPP Internal connection terminal 45 P18 O Segment output terminal of P18.
6 ~RESET I System reset signal input terminal. 46 P17 O Segment output terminal of P17.
7 SUBCL/SCK I Clock input terminal to transmit the signal from main microprocessor. 47 P16 O Segment output terminal of P16.
8 SUBDO/SDI I Data input terminal to transmit the signal from main microprocessor. 48 P15 O Segment output terminal of P15.
9 SUBDI/SDD O Data output terminal to transmit the signal to main microprocessor. 49 P14 O Segment output terminal of P14.
10 SUBLDY O Data ready output terminal to transmit to the main microprocessor. 50 P13 O Segment output terminal of P13.
11 VBJ I Pulse input terminal from the rotary encoder of volume. 51 P12 O Segment output terminal of P12.
12 VAJ I Pulse input terminal from the rotary encoder of volume. 52 P11 O Segment output terminal of P11.
13 SSCBJ I Not used. 53 P10 O Segment output terminal of P10.
14 SSCAJ I Not used. 54 P9 O Segment output terminal of P9.
15 ~IRIN I Not used. 55 P8 O Segment output terminal of P8.
16 ~IRF I Signal input terminal from the remote controller. 56 P7 O Segment output terminal of P7.
17 STBYLED O Standby LED control output terminal. 57 P6 O Segment output terminal of P6.
18 AVSS Ground terminal for A/D converter. 58 P5 O Segment output terminal of P5.
19 K3 I Operation key connection terminal. 59 VDD2 Power supply terminal. Apply +5V.
20 K2 I Operation key connection terminal. 60 VLOAD Negative power supply terminal of FL controller.
21 K1 I Operation key connection terminal. 61 P4 O Segment output terminal of P4.
22 K0 I Operation key connection terminal. 62 P3 O Segment output terminal of P3.
23 VSS0 Ground terminal 63 P2 O Segment output terminal of P2.
24 AVDD Power supply terminal for A/D converter. 64 P1 O Segment output terminal of P1.
25 VDDD Power supply terminal. Apply +5V. 65 16G O Grid output terminal of 16G.
26 ~SYSIN I System code input terminal. 66 15G O Grid output terminal of 15G.
27 ~SYSOUT O System code output terminal. 67 14G O Grid output terminal of 14G.
28 P35 O Segment output terminal of P35. 68 13G O Grid output terminal of 13G.
29 P34 O Segment output terminal of P34. 69 12G O Grid output terminal of 12G.
30 P33 O Segment output terminal of P33. 70 11G O Grid output terminal of 11G.
31 P32 O Segment output terminal of P32. 71 10G O Grid output terminal of 10G.
32 P31 O Segment output terminal of P31. 72 9G O Grid output terminal of 9G.
33 P30 O Segment output terminal of P30. 73 8G O Grid output terminal of 8G.
34 P29 O Segment output terminal of P29. 74 7G O Grid output terminal of 7G.
35 P28 O Segment output terminal of P28. 75 6G O Grid output terminal of 6G.
36 P27 O Segment output terminal of P27. 76 5G O Grid output terminal of 5G.
37 P26 O Segment output terminal of P26. 77 4G O Grid output terminal of 4G.
38 P25 O Segment output terminal of P25. 78 3G O Grid output terminal of 3G.
39 P24 O Segment output terminal of P24. 79 2G O Grid output terminal of 2G.
40 P23 O Se
g
ment out
p
ut terminal of P23. 80 1G O Grid out
p
ut terminal of 1G.
HT-R410
TERMINAL DESCRIPTION
SUB MICROPROCESSOR
HT-R410

Onkyo HT-R410 Specifications

Amplifier Section

Power Output Front L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Power Output Center Speaker	100 Watts min. RMS at 8 ohms, 20-20, 000 Hz, 0.08% THD
Power Output Surround L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Dynamic Power Output at 3 ohms	230 watts × 2
Dynamic Power Output at 4 ohms	170 watts × 2
Dynamic Power Output at 8 ohms	115 watts × 2

Input and Output Impedance

Digital Input Optical	0.5 Vp-p, 75 ohms
Digital Input Coaxial	0.5 Vp-p, 75 ohms
Line Input (CD, VIDEO 1, 2, 3, TAPE)	200 mV, 47 kohms
Multichannel Input (DVD FRONT L/C/R, SURR L/R)	200 mV, 47 kohms
Multichannel Input (SUBWOOFER)	36 mV, 47 kohms
Output Level Rec out (TAPE, VIDEO 1)	200 mV, 470 ohms
Output Level Pre out (SUBWOOFER)	1 V, 470 ohms

Tuner Section

FM Tuning Range	87.5-108.0 MHz (100 kHz steps)
FM Usable Sensitivity Mono	11.2 dBf, 1.0 µV (75 ohms, IHF)
FM Usable Sensitivity Stereo	17.2 dBf, 2.0 µV (75 ohms, IHF)
FM 50 dB Quieting Sensitivity Mono	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB Quieting Sensitivity Stereo	37.2 dBf, 20.0 µV (75 ohms)
FM Capture Ratio	2.0 dB
FM Image Rejection Ratio	40 dB
FM IF Rejection Ratio	90 dB
FM Signal-to-Noise Ratio Mono	76 dB, IHF
FM Signal-to-Noise Ratio Stereo	70 dB, IHF
FM Alternate Channel Attenuation	55 dB, IHF, ±400 kHz
FM Selectivity	50 dB (DIN)
FM AM Suppression Ratio	50 dB
FM Total Harmonic Distortion Mono	0.2%
FM Total Harmonic Distortion Stereo	0.3%
FM Frequency Response	30 Hz-15 kHz, ±1.0 dB
FM Stereo Separation at 1 kHz	45 dB
FM Stereo Separation at 100 Hz-10 kHz	30 dB
AM Tuning Range	530-1, 710 kHz (10 kHz steps)
AM Usable Sensitivity	30 µV
AM Image Rejection Ratio	40 dB
AM IF Rejection Ratio	40 dB
AM Signal-to-Noise Ratio	40 dB
AM Total Harmonic Distortion	0.7%

General Specifications

Power Supply	AC 120 V, 60 Hz
Power Consumption	4.7 A
Dimensions (W × H × D)	17-1/8” × 5-7/8” × 14-3/8”
Dimensions in mm (W × H × D)	435 × 150 × 365 mm
Weight	19.0 lbs., 8.6 kg
