14
Connecting a satellite tuner or television
Using an RCA-type video connection cable, connect the video
output terminal (composite) on the satellite tuner or television to
the VIDEO 1 IN VIDEO jacks on the HT-R490.
If there is an S video output terminal on the satellite tuner or
television, connect it to the VIDEO 1 IN S VIDEO jack using an S
video cable.
Using an RCA-type audio connection cable, connect the audio
output terminal on the satellite tuner or television to the same
VIDEO 1 IN L/R jacks on the HT-R490. Make sure that you
properly connect the left channel to the L jack and the right
channel to the R jack.
If the satellite tuner or television has a digital output jack as well,
be sure to also connect it to either a DIGITAL INPUT OPTICAL
or COAXIAL jack on the HT-R490 depending on the type of
connector on the satellite tuner or television.
With the initial settings of the HT-R490, the DIGITAL INPUT
jack for the VIDEO 1 source is not assigned. If you connect the
video cassette recorder to the DIGITAL INPUT jack, then this
input source must be set for digital input at the DIGITAL INPUT
button (see page 12).
Connecting a television monitor or projector
Using an RCA-type video connection cable, connect the video
input terminal (composite) on the monitor to the MONITOR OUT
VIDEO jack on the HT-R490.
If there is an S video input terminal on the monitor, connect it to
the MONITOR OUT S VIDEO jack using an S video cable.
Example of how to connect your equipment
Connecting your video components
Connecting a DVD player or LD player
Using an RCA-type video connection cable, connect the video
output terminal (composite) on the device to the DVD IN VIDEO
jack on the HT-R490.
If there is an S video output terminal on the DVD player or LD player,
connect it to the DVD IN S VIDEO jack using an S video cable.
Using an RCA-type audio connection cable, connect the audio
output terminal on the DVD player or LD player to the audio DVD
IN L/R jacks on the HT-R490. Make sure that you properly
connect the left channel to the L jack and the right channel to the R
jack.
If the DVD player or LD player has a digital output jack as well, be
sure to also connect it to either a DIGITAL INPUT OPTICAL or
COAXIAL jack on the HT-R490 depending on the type of
connector on the DVD player or LD player.
With the initial settings of the HT-R490, the DVD input source is
set for digital input at the COAXIAL jack. If the digital connection
is made at a different jack, this must be changed (see page 12).
Connecting a video cassette recorder
Using an RCA-type video connection cable, connect the video
output terminal (composite) on the video cassette recorder to the
VIDEO 2 IN VIDEO jack on the HT-R490 and video input
terminal to the VIDEO 2 OUT VIDEO jack.
Using an RCA-type audio connection cable, connect the audio
output terminal on the video cassette recorder to the same VIDEO
2 IN L/R jacks on the HT-R490 and audio input terminal to the
VIDEO 2 OUT L/R jacks. Make sure that you properly connect the
left channel to the L jack and the right channel to the R jack.
If the video cassette recorder has a digital output jack as well, be
sure to also connect it to either a DIGITAL INPUT OPTICAL or
COAXIAL jack on the HT-R490 depending on the type of
connector on the video cassette recorder.
With the initial settings of the HT-R490, the DIGITAL INPUT
jack for the VIDEO 2 source is not assigned. If you connect the
video cassette recorder to the DIGITAL INPUT jack, then this
input source must be set for digital input at the DIGITAL INPUT
button (see page 12).
To Next Page
