Onkyo HT-R508 User Manual

6
Features
Amplifier
• 5-channel amplifier
• 110 watts per channel rms into 8 ohms, 2 channels
driven at 1 kHz, less than 0.9% total harmonic distor-
tion (FTC rating)
• WRAT (Wide Range Amplifier Technology)
• Optimum Gain Volume Circuitry
• Audyssey 2EQ room correction
*1
Processing
• Dolby
*2
Digital
• DTS, DTS Neo:6, and DTS 96/24
*3
• Theater-Dimensional
*4
virtual surround sound
• Linear PCM 192 kHz/24-bit D/A converters on all
channels
• Pure Audio listening mode
•Powerful and highly accurate 32-bit DSP processing
Audio/Video
•2 HDMI
*5
inputs, 1 output
• Adjustable crossover (40, 50, 60, 80, 100, 120, 150,
200 Hz)
• HDTV-capable component video (3 inputs, 1 output)
•3 S-Video inputs, 2 outputs
•4 assignable digital inputs (2 optical, 2 coaxial)
• Subwoofer pre out
• Color-coded 5.1 multichannel input for use with Super
Audio CD and DVD-Audio
• Color-coded speaker terminal posts
Tuner
• 40 radio presets
• AM/FM auto tuning
• RDS (Radio Data System)
Remote Controller
• Preprogrammed for use with other AV components
*1
Manufactured under license from Audyssey Laboratories.
U.S. and foreign patents pending. Audyssey 2EQ is a trade-
mark of Audyssey Laboratories.
*2
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are regis-
tered trademarks of Dolby Laboratories.
*3
“DTS” and “Neo: 6” are registered trademarks of DTS, Inc.
“96/24” is a trademark of DTS, Inc.
*4
Theater-Dimensional is a trademark of Onkyo Corpora-
tion.
*5
HDMI, the HDMI logo and High Definition Multimedia
Interface are trademarks or registered trademarks of HDMI
Licensing, LLC. This unit incorporates HDMI technology.
HT-R508En.book Page 6 Wednesday, March 14, 2007 10:12 AM

Onkyo HT-R508 Specifications

Amplifier Section

rated output power (FTC)	110 watts
rated output power (IEC)	5 ch × 130 W
maximum output power (JEITA)	5 ch × 160 W
dynamic power (3Ω, 1 ch driven)	210 W
dynamic power (4Ω, 1 ch driven)	190 W
dynamic power (8Ω, 1 ch driven)	130 W
total harmonic distortion (THD)	0.08%
damping factor	60
input sensitivity and impedance	200 mV/ 47 kΩ
output level and impedance	200 mV/ 470 Ω
frequency response	5 Hz–100 kHz
tone control (bass)	±10 dB, 50 Hz
tone control (treble)	±10 dB, 20 kHz
signal to noise ratio	100 dB
speaker impedance	8Ω–16Ω

Video Section

input sensitivity/output level and impedance (component and s-video y)	1 Vp-p /75Ω
input sensitivity/output level and impedance (component pb/cb, pr/cr)	0.7 Vp-p /75Ω
input sensitivity/output level and impedance (s-video c)	0.28 Vp-p /75Ω
input sensitivity/output level and impedance (composite)	1 Vp-p /75Ω
component video frequency response	5 Hz – 50 MHz

Tuner Section

fm tuning frequency range	87.5 MHz– 108.0 MHz
am tuning frequency range	522 kHz–1611 kHz
radio presets	40

General

power supply	AC 230 V, 50 Hz
power consumption	560 W
standby power consumption	0.3 W
dimensions (W × H × D)	435 × 150 × 377 mm
weight	10.2 kg
