■ Listening Modes
Listening Mode Description Input
Source
Speaker
Layout
Direct In this mode, audio from the input source is
output without surround-sound processing.
The speaker configuration (presence of
speakers) and speaker distance settings are
enabled, but much of the processing set via
Home menu is disabled. A/V Sync does not
have effect on the analog audio. See “On-
screen Setup” for more details
(➔ page 35).
A
S
D
F
ZXC
Stereo Sound is output from the front left and right
speakers and subwoofer.
Mono Use this mode when watching an old movie
with a mono soundtrack, or use it with the
foreign language soundtracks recorded in the
left and right channels of some movies. It
can also be used with DVDs or other sources
containing multiplexed audio, such as
karaoke DVDs.
Multichannel This mode is for use with PCM multichannel
sources.
D
F
XC
Di rec t
Stereo
Mono
Mu l t i ch
DSD
*2
In this mode, audio from the input source is
output without surround-sound processing.
The speaker configuration (presence of
speakers), crossover frequency, speaker
distance, A/V Sync and much of the
processing set via Home menu are enabled.
See “On-screen Setup” for more details
(➔ page 35).
DXC
Dolby Digital
Dolby Digital Plus
*3
D
F
XC
Dolby TrueHD
DTS
DXC
DTS-HD High
Resolution Audio
D
F
XC
DTS-HD Master
Audio
DTS Express
DXC
DTS 96/24 This mode is for use with DTS 96/24
sources. This is high-resolution DTS with a
96 kHz sampling rate and 24-bit resolution,
providing superior fidelity. Use it with
DVDs that bear the DTS 96/24 logo.
DXC
Listening Mode Description Input
Source
Speaker
Layout
DSD
Dolby D
Dolby D +
Dolby TrueHD
DTS
DTS– HD HR
DTS– HD MSTR
DTS Ex p r e s s
DTS 9 6 / 24

Onkyo HT-RC430 Specifications

General

Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (20-20KHz@8 Ohm)	60 W
HDMI in	4
Audio (L/R) in	6
Composite video in	5
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
3D	Yes
Supported video modes	1080p
Display	-
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	40 W

Weight and Dimensions

Depth	318 mm
Width	435 mm
Height	150 mm
Weight	7600 g
