32
Connecting the AV Receiver/AV Amplifier—Continued
With this hookup, you can use your VCR’s tuner to listen to your favorite TV programs via the AV
receiver/AV amplifier, useful if your TV has no audio outputs.
• With connection , you can listen to the VCR or DVD recorder even in Zone 2.
• To enjoy Dolby Digital and DTS, use connection or . (To listen in Zone 2 as well, use and , or and
.)
.
Connecting a VCR or DVD Recorder for Playback
Hint!
Step 1: Video Connection
Choose a video connection that matches your VCR or DVD recorder ( , , or
), and then make the connection.
You must connect the AV receiver/AV amplifier to your TV via the same type of connection.
A B C
Step 2: Audio Connection
Choose an audio connection that matches your VCR or DVD recorder ( , , or ), and then make the connection.
a b c
a
b c a b a
c
Connection AV receiver/AV amplifier Signal flow VCR or DVD recorder Picture quality
COMPONENT VIDEO IN 2
⇐
Component video output Best
VCR/DVR IN S
⇐
S-Video output Better
VCR/DVR IN V
⇐
Composite video output Standard
VCR/DVR IN L/R
⇐
Analog audio L/R output
DIGITAL COAXIAL IN 2 (VCR/DVR)
⇐
Digital coaxial output
DIGITAL OPTICAL IN 1 (GAME/TV)
⇐
Digital optical output
A
B
C
a
b
c
YCOAXIAL
OUT
PB
COMPONENT VIDEO OUT
P
R S VIDEO
OUT
AUDIO
OUT
VIDEO
OUT
LR
OPTICAL
OUT
b
c
A
B
C
B
a
C
VCR,
DVD recorder
Connect one or the other
Connection must be assigned (see page 51)
c
Connection
must be
assigned
(see
page 49)
A
TX-SR705_En.book Page 32 Monday, May 28, 2007 2:13 PM
