Connecting the AV Receiver/AV Amplifier—Continued
About HDMI
Designed to meet the demands of digital TV, HDMI (High Definition Multimedia Interface) is a new digital interface
standard for connecting TVs, projectors, DVD players, set-top boxes, and other video components. Until now, several
separate video and audio cables have been required to connect AV components. With HDMI, a single cable can carry
control signals, digital video, and up to eight channels of digital audio (2-channel PCM, multichannel digital audio, and
multichannel PCM).
The HDMI video stream (i.e., video signal) is compatible with DVI (Digital Visual Interface)
*1
, so TVs and displays
with a DVI input can be connected by using an HDMI-to-DVI adapter cable. (This may not work with some TVs and
displays, resulting in no picture.)
The AV receiver/AV amplifier uses HDCP (High-bandwidth Digital Content Protection)
*2
, so only HDCP-compatible
components can display the picture.
Supported Audio Formats
• 2-channel linear PCM (32–192 kHz, 16/20/24 bit)
• Multichannel linear PCM (up to 7.1 ch, 32–192 kHz, 16/20/24 bit)
• Bitstream (Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS-HD High Resolution Audio, DTS-HD
Master Audio)
Your DVD player must also support HDMI output of the above audio formats.
About Copyright Protection
The AV receiver/AV amplifier supports HDCP (High-bandwidth Digital Content Protection)
*2
, a copy-protection sys-
tem for digital video signals. Other devices connected to the AV receiver/AV amplifier via HDMI must also support
HDCP.
Commercially available HDMI cables (supplied with some components) should be used to connect the AV receiver/AV
amplifier’s HDMI OUT to the HDMI input on your TV or projector.
*1 DVI (Digital Visual Interface): The digital display interface standard set by the DDWG
*3
in 1999.
*2 HDCP (High-bandwidth Digital Content Protection): The video encryption technology developed by Intel for HDMI/DVI. It’s designed to
protect video content and requires a HDCP-compatible device to display the encrypted video.
*3 DDWG (Digital Display Working Group): Lead by Intel, Compaq, Fujitsu, Hewlett Packard, IBM, NEC, and Silicon Image, this open
industry group’s objective is to address the industry's requirements for a digital connectivity specification for high-performance PCs and
digital displays.
Connecting Components with HDMI
The AV receiver/AV amplifier’s HDMI interface is based on the following standard:
High-Definition Multimedia Interface Specification Informational Version 1.3a
