Onkyo SR705 - TX AV Receiver User Manual

83
Advanced Setup—Continued
Notes:
• When the listening mode is set to Direct or Pure
Audio, no effect will be produced.
• Depending on the input source or listening mode, the
Equalizer settings may not produce the desired effect.
• This procedure can also be performed on the AV
receiver/AV amplifier by using its [SETUP] button,
arrow buttons, and [ENTER] button.
THX Audio Setup
With the Surr Back Sp Spacing setting, you can specify
the distance between your surround back speakers.
6
Use the Up and Down [ ]/[ ]
buttons to select a frequency,
and then use the Left and Right
[ ]/[ ] buttons to adjust the
level at that frequency.
The volume at each frequency can be
adjusted from –6 to +6 dB in 1 dB
steps.
Tip: Low frequencies (e.g., 160 Hz)
affect bass sounds; high frequencies
(e.g., 6300 Hz) affect treble sounds.
7
Use the Up [ ] button to select
“Channel,” and then use the Left
and Right [ ]/[ ] buttons to
select another speaker.
Repeat step 6 and 7 for each speaker.
8
Press the [SETUP] button.
The setup menu closes.
ENTER
ENTER
ENTER
ENTER
1
Press the [RECEIVER] REMOTE
MODE button, followed by the
[SETUP] button.
The main menu appears onscreen.
2
Use the Up and Down [ ]/[ ]
buttons to select “2. Speaker
Setup,” and then press [ENTER].
The Speaker Setup menu appears.
3
Use the Up and Down [ ]/[ ]
buttons to select “6. THX Audio
Setup,” and then press [ENTER].
The THX Audio Setup screen appears.
These settings are not set automatically by the Auto-
matic Speaker Setup function (see page 54).
ENTER
ENTER
2. Speaker Setup
1. Speaker Settings
2. Speaker Config
3. Speaker Distance
4. Level Calibration
5. Equalizer Settings
6. THX Audio Setup
ENTER
ENTER
2–6. THX Audio Setup
Surr Back Sp Spacing <1ft
TX-SR705_En.book Page 83 Monday, May 28, 2007 2:13 PM
