Onkyo TX-SR303 Service Manual

1/24 PAGE
TX-SR303/303E
<Notes>
<303> : TX-SR303 Only
<303E> : TX-SR303E(European model) Only
EXPLODED VIEW PARTS LIS
T
REF. NO. NAME DESCRIPTION Q'TY PART NO REMARKS
EXP
A001 RETAINER (F) 1 27141972
EXP
A002 SCREW 3TTB+10B(BC) 13 838430108
EXP
A003 SCREW 3TTB+8B(BC) 36 838430088
EXP
A004 SCREW 3TTB+8B(CU)SR 20 801618
EXP
A010 CHASSIS --- (1) 27100460A
EXP
A011 TAPE TAPE(CLOTH-16U) (1) 29110083
EXP
A013 WIRE TIE BSK-1 6 260208
EXP
A014 CLIP CS-1U 2 27255004
EXP
A015 HOLDER KGLS-14RT 3 27190524
EXP
A016 HOLDER HOLDER 2 27190991
EXP
A023 SCREW 4TTC+8C(BC) 4 830440089
EXP
A025 TAPE TAPE(CLOTH-16U) (1) 29110083
EXP
A028 BUSHING S-RELIEF #2271 1 27300750
!
EXP
A030 HEAT SINK AS 1 27160563B
EXP
A037 SCREW 3SMS8W.SW+14B(BC) 10 801433
EXP
A040 BRACKET (U) 1 27130986
EXP
A045 SHLD PLT (R) 1 27150504
EXP
A045 SHLD PLT (R) 1 27150504
EXP
A046 PLA RIVET P3035B 1 880016
EXP
A046 PLA RIVET P3035B 1 880016
EXP
A048 CUSHION t3x50x10 2 28141563
EXP
A050 COVER --- 1 28184926
EXP
A051 SCREW 3TTB+8B(UN) 6 838930088
EXP
A052 LABEL (COVER) 1 29364123
EXP
A055 LEG LEG 4 27175319B
EXP
A056 CUSHION --- 8 28141494
EXP
A065 CLEAR PLT --- 1 28192065A
EXP
A401 REAR PANEL TX-SR303MDD 1 27123404A
<303>
EXP
A401 REAR PANEL TXSR303MPP 1 27123454
<303E>
EXP
A405 F PANEL --- 1 27212769A
<303>
EXP
A405 F PANEL --- 1 27212789
<303E>
EXP
A406 FACET (ST) 1 28198998A
EXP
A411 KNOB (POW) 1 28326299
EXP
A412 KNOB (SEL) 1 28326303
EXP
A413 KNOB (PRE) 1 28326306
EXP
A420 BADGE --- 1 28135298
EXP
A425 RETAINER (BRO) 1 27141873
<303E>
EXP
A430 KNOB (VOL)AS 1 28326319
EXP
A450 LABEL HOOKUP-ONKYO 1 29363194
<303>
EXP
F901 FUSE 6.3A-UL/T-237 1 252166
!, <303>
EXP
F901 or FUSE 6.3A-T/UL-ST2 ( 1) 252260
!, <303>
EXP
F902 FUSE 3.15A-SE-EAK FUSE 1 252076
!, <303E.
EXP
F902 or FUSE 3.15A-SE-TL250V ( 1) 252242
!, <303E.
EXP
F902 or FUSE 3.15A-SE-TL250V ( 1) 252276
!, <303E.
EXP
F6901 FUSE 8A-UL 1 252198
!, <303>
EXP
F6901 or FUSE 8A-T/UL-ST2 ( 1) 252261
!, <303>
EXP
F6901 FUSE 8A-UL 1 252198
!, <303E>
EXP
F6901 or FUSE 8A-T/UL-ST2 ( 1) 252261
!, <303E>
EXP
F6902 FUSE 8A-UL 1 252198
!
EXP
F6902 or FUSE 8A-T/UL-ST2 ( 1) 252261
!
EXP
P101 FFC NCFC7-150512 1 2047150512
EXP
P703 FFC NCFC5-232022 1 2045232022
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PAR
T
NUMBER SPECIFIED.
