Onkyo TX-SR303

12/24 PAGE
PCB1
S838 PUSH SW NPS-111-S681 1 25035718
PCB1
S838 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB1
S839 PUSH SW NPS-111-S681 1 25035718
PCB1
S839 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB1
S851 R ENCODE EC12E2425 1 25065655
PCB1
E301 TRM NTM-1P233(M1969) 1 25060302
PCB1
E301A ISO PLT --- 1 28175316
PCB1
E891 RETAINER KANAGU 1 27141059
PCB1
JL832A WIRE HOL NSCT-3P894 1 25051107
PCB1
JL832B WIRE HOL NSCT-3P894 1 25051107
PCB1
JL891A WIRE HOL NSCT-5P896 1 25051109
U05 AMPLIFIER PC BOARD (NAAF-8523-1A)
U06 SEC. TERMINAL-2 PC BOARD (NAPS-8524-1A)
U07 SBR AMPLIFIER PC BOARD (NAETC-8525-1A)
U08 THERMAL SENSOR PC BOARD (NAETC-8526-1A)
U09 HOLDER PC BOARD (NAETC-8527-1A)
CIRCUIT N
O
NAME DESCRIPTION Q'TY PART NO REMARKS
PCB2
Q5501 IC NJW1157B 1 22242193R3
PCB2
Q5502 IC NJU7311AM 1 22242209R2
PCB2
Q5503 IC NJM4580M-D 1 22241448R2
PCB2
Q5600 TR RN1441 1 2215410R2
PCB2
Q5601 TR RN1441 1 2215410R2
PCB2
Q5602 TR RN1441 1 2215410R2
PCB2
Q5603 TR RN1441 1 2215410R2
PCB2
Q5604 TR RN1441 1 2215410R2
PCB2
Q5607 TR RN1441 1 2215410R2
PCB2
Q5617 TR RN1441 1 2215410R2
PCB2
Q5630 IC NJM4580M-D 1 22241448R2
PCB2
Q5640 IC AN34060A 1 22242205
PCB2
Q5660 IC(REGURATOR) 7812HF(TA7812S) 1 222780124TOS
PCB2
Q5660 or IC(REGULATOR) 78M12HF ( 1) 222780125
PCB2
Q5660A SCREW 3P+10FN(BC) 1 82143010
PCB2
Q5661 IC(REGURATOR) 79012HF(TA79012S) 1 222790124TOS
PCB2
Q5661 or IC(REGULATOR) 79M12HF ( 1) 222790125
PCB2
Q5661A SCREW 3P+10FN(BC) 1 82143010
PCB2
Q5661B HEAT SINK RAD-213 1 27160570
PCB2
Q6010 TR 2SC1740S-S 1 2213285
PCB2
Q6011 TR 2SC1740S-S 1 2213285
PCB2
Q6012 TR 2SC1740S-S 1 2213285
PCB2
Q6013 TR 2SC1740S-S 1 2213285
PCB2
Q6014 TR 2SC1740S-S 1 2213285
PCB2
Q6020 TR 2SC1740S-S 1 2213285
PCB2
Q6021 TR 2SC1740S-S 1 2213285
PCB2
Q6022 TR 2SC1740S-S 1 2213285
PCB2
Q6023 TR 2SC1740S-S 1 2213285
PCB2
Q6024 TR 2SC1740S-S 1 2213285
PCB2
Q6030 TR 2SC5171 1 2203010
PCB2
Q6030 or TR 2SC5993-Q,P ( 1) 2217161
PCB2
Q6031 TR 2SC5171 1 2203010
PCB2
Q6031 or TR 2SC5993-Q,P ( 1) 2217161
PCB2
Q6032 TR 2SC5171 1 2203010
PCB2
Q6032 or TR 2SC5993-Q,P ( 1) 2217161
PCB2
Q6033 TR 2SC5171 1 2203010
PCB2
Q6033 or TR 2SC5511-E ( 1) 2203845
PCB2
Q6034 TR 2SC5171 1 2203010
PCB2
Q6034 or TR 2SC5511-E ( 1) 2203845
PCB2
Q6040 TR 2SA1930 1 2203000
PCB2
Q6040 or TR 2SA2140-Q,P ( 1) 2217151
PCB2
Q6041 TR 2SA1930 1 2203000
PCB2
Q6041 or TR 2SA2140-Q,P ( 1) 2217151
PCB2
Q6042 TR 2SA1930 1 2203000
PCB2
Q6042 or TR 2SA2140-Q,P ( 1) 2217151
PCB2
Q6043 TR 2SA1930 1 2203000
PCB2
Q6043 or TR 2SA2005-E ( 1) 2203835
PCB2
Q6044 TR 2SA1930 1 2203000
PCB2
Q6044 or TR 2SA2005-E ( 1) 2203835
PCB2
Q6070 TR 2SC2240-GR 1 2211405
PCB2
Q6070 or TR 2SC2240-BL ( 1) 2211406
PCB2
Q6071 TR 2SC2240-GR 1 2211405
PCB2
Q6071 or TR 2SC2240-BL ( 1) 2211406
PCB2
Q6072 TR 2SC2240-GR 1 2211405
PCB2
Q6072 or TR 2SC2240-BL ( 1) 2211406
PCB2
Q6073 TR 2SC2240-GR 1 2211405
PCB2
Q6073 or TR 2SC2240-BL ( 1) 2211406
