Onkyo TX-SR303 - Page 94

19/24 PAGE
U13 POWER SUPPLY-2 PC BOARD (NAPS-8546-1A/1J)
U14 SEC. TERMINAL-1 PC BOARD (NAPS-8547-1A/1J)
U15 SPEAKER TERMINAL PC BOARD (NAETC-8548-1A/1J)
U16 VIDEO PC BOARD (NAVD-8549-1A/1J)
U17 DRIVER AMPLIFIER PC BOARD (NAAF-8550-1A/1J)
CIRCUIT N
O
NAME DESCRIPTION Q'TY PART NO REMARKS
PCB3
Q1001 TR RN1241-A 1 2213631
PCB3
Q1001 or TR RN1241-B ( 1) 2213632
PCB3
Q1002 TR RN1241-A 1 2213631
PCB3
Q1002 or TR RN1241-B ( 1) 2213632
PCB3
Q1003 IC LA7956 1 22241759
PCB3
Q1004 TR 2SA933S-R 1 2213354
PCB3
Q1004 or TR 2SA933S-S ( 1) 2213355
PCB3
Q1004 or TR KTA1267-GR ( 1) 2215995
PCB3
Q1005 TR DTA114ES 1 2213510
PCB3
Q1005 or TR KRA102M ( 1) 2215770
PCB3
Q1006 TR DTA114ES 1 2213510
PCB3
Q1006 or TR KRA102M ( 1) 2215770
PCB3
Q1015 TR RN1241-A 1 2213631
PCB3
Q1015 or TR RN1241-B ( 1) 2213632
PCB3
Q1016 TR RN1241-A 1 2213631
PCB3
Q1016 or TR RN1241-B ( 1) 2213632
PCB3
Q1018 TR RN1241-A 1 2213631
PCB3
Q1018 or TR RN1241-B ( 1) 2213632
PCB3
Q5000 TR 2SC2240-BL 1 2211406
PCB3
Q5001 TR 2SC2240-BL 1 2211406
PCB3
Q5002 TR 2SC2240-BL 1 2211406
PCB3
Q5003 TR 2SC2240-BL 1 2211406
PCB3
Q5003 or TR KTC3200-BL ( 1) 2215896
PCB3
Q5004 TR 2SC2240-BL 1 2211406
PCB3
Q5004 or TR KTC3200-BL ( 1) 2215896
PCB3
Q5010 TR 2SC2240-BL 1 2211406
PCB3
Q5011 TR 2SC2240-BL 1 2211406
PCB3
Q5012 TR 2SC2240-BL 1 2211406
PCB3
Q5013 TR 2SC2240-BL 1 2211406
PCB3
Q5013 or TR KTC3200-BL ( 1) 2215896
PCB3
Q5014 TR 2SC2240-BL 1 2211406
PCB3
Q5014 or TR KTC3200-BL ( 1) 2215896
PCB3
Q5030 TR 2SA949-Y 1 2211354
PCB3
Q5031 TR 2SA949-Y 1 2211354
PCB3
Q5032 TR 2SA949-Y 1 2211354
PCB3
Q5033 TR 2SA949-Y 1 2211354
PCB3
Q5034 TR 2SA949-Y 1 2211354
PCB3
Q5040 TR 2SC2229-Y 1 2211634
PCB3
Q5041 TR 2SC2229-Y 1 2211634
PCB3
Q5042 TR 2SC2229-Y 1 2211634
PCB3
Q5043 TR 2SC2229-Y 1 2211634
PCB3
Q5044 TR 2SC2229-Y 1 2211634
PCB3
Q5050 TR 2SC1815-GR 1 2211255
PCB3
Q5050 or TR 2SC1815-BL ( 1) 2211256
PCB3
Q5051 TR 2SC1815-GR 1 2211255
PCB3
Q5051 or TR 2SC1815-BL ( 1) 2211256
PCB3
Q5052 TR 2SC1815-GR 1 2211255
PCB3
Q5052 or TR 2SC1815-BL ( 1) 2211256
PCB3
Q5053 TR 2SC1815-GR 1 2211255
PCB3
Q5053 or TR 2SC1815-BL ( 1) 2211256
PCB3
Q5054 TR 2SC1815-GR 1 2211255
PCB3
Q5054 or TR 2SC1815-BL ( 1) 2211256
PCB3
Q9002 TR KTA1268-GR 1 2215885
PCB3
Q9002 or TR KTA1268-BL ( 1) 2215886
PCB3
Q9002 or TR 2SA970-GR ( 1) 2211395
PCB3
Q9002 or TR 2SA970-BL ( 1) 2211396
PCB3
Q921 TR 2SC2458-GR 1 2212115
PCB3
Q921 or TR 2SC2458-BL ( 1) 2212116
PCB3
Q921 or TR KTC3199-GR ( 1) 2215864
PCB3
D1001 DIODE 1SS133(DS) 1 223280
PCB3
D1001 or DIODE 1SS133 ( 1) 223163
PCB3
D1001 or DIODE 1SS270A ( 1) 223205
PCB3
D1002 DIODE 1SS133(DS) 1 223280
PCB3
D1002 or DIODE 1SS133 ( 1) 223163
PCB3
D1002 or DIODE 1SS270A ( 1) 223205
PCB3
D5000 ZENER D DZ-5.6BSB 1 224850562
PCB3
D5000 or ZENER D MTZJ5.6B ( 1) 224470562
PCB3
D5001 ZENER D DZ-5.6BSB 1 224850562
PCB3
D5001 or ZENER D MTZJ5.6B ( 1) 224470562
