Onkyo TX-SR393

24
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
 3.1.2 Channel System
1
3
2
45
6
This is a combination of the 3.1 Channel System and front high speakers. A front high speaker is a type of height speaker.
You can select only one set of height speakers from the following three types for connection.
❏ Front High Speakers Installation Example ( p18)
❏ Ceiling Speakers Installation Example ( p19)
❏ Dolby Enabled Speakers (Dolby Speakers) Installation Example ( p20)
 "Speaker Setup" settings during
Initial Setup ( p80)
Speaker Setup
Select how many speakers you have.
Next
ENTER
Speaker Channels
Speaker Impedance
3.1.2 ch
Yes
6 ohms or above
Subwoofer
Front HighHeight Speaker
• Speaker Channels: 3.1.2 ch
• Subwoofer: Yes
• Height Speaker: Select the
type of height speaker actually
installed.
• Speaker Impedance: Set any
value ( p21)
