Onkyo TX-SR500/E - Page 15

P6011
TO NAAF-7409
(SCH.4-2)
JL6952A
TO NAPS-7421
(SCH.6-2)
JL6951A
TO NAPS-7421
(SCH.6-2)
F6901
*
F6902
*
RL6901
RL6902
D6903
RS603M
RBV602
D5SBA20
D6903,6904:
D6904
0.1V
0.8V
-50V
-0.5V
0.5V
1.1V
-1V
-0.5V
1V
0.2V
-0.3V
-0.3V
0.5V
50V
0V
0V
-50V
-0.5V
0.5V
1.1V
-1V
-0.5V
1V
0.2V
-0.3V
-0.3V
0.5V
50V
0V
0V
Q6901
Q6034
Q6074
Q6024
Q6014
Q6054
Q6033
Q6073
Q6023
Q6013
Q6053
R6902
1K
R6904
(1/2W)
R6905
(1/2W)
R6512
(1/2W)
R6523
(1/2W)
R6513
(1/2W)
R6522
(1/2W)
R6054
3.9K
R6084
2.2
(1/4W)
R6184
47K
R6074
100
(1/4W)
R6134
R6234
8.2
(1W)
R6014
3.9K
R6004
5.6K
R6034
470
R6164
33K
R6154
4.7K
R6144
22K
R6094
2.2
(1/4W)
R6174
47K
R6053
3.9K
R6083
2.2
(1/4W)
R6183
47K
R6073
100
(1/4W)
R6133
R6233
8.2
(1W)
R6013
3.9K
R6003
5.6K
R6033
470
R6163
33K
R6153
4.7K
R6143
22K
R6093
2.2
(1/4W)
R6173
47K
C6902
C6901
10000/56
C6901,2:
(TX-SR500(E)/TX-SA500)
10000/71
(HT-R500)
C6522
C6512
C6513C6523
C6044
47/50
C6043
47/50
C6906
104J
C6907
104J
C6904
334J
[334J
/100]
C6905
334J
[334J
/100]
C6034
C6234
473J
C6054
C6033
C6233
473J
C6053
R6044
1K
R6043
1K
R6104
0.22
X2
(2W)
R6103
0.22
X2
(2W)
D6906
D6705
D6706
D6902 D6901
D6004
D6003
R6024
R6023
P6004
TO NAAF-7409
(SCH.4-1)
P6003
TO NAAF-7409
(SCH.4-1)
P931
TO NAPS-7420
(SCH.6-1)
Q6044
Q6064
Q6043
Q6063
C6903
104J
C6920
C6708
223Z
P6906
P6084
ID+
ID-
P6083
ID+
ID-
NF
-B1 E
+B1 E
B+ E
B- E
E
E
E
E
E
NF
-B1
+B1
B+
B-
+13VS
+13VS
MPUGND
MPUGND
POWER
SEMICONDUCTORS
NO.
Q6010-6014 2SC1740S-R,S
Q6020-6024 2SC1740S-R,S
Q6030-6034 KTD2061-Y OR 2SC5171
Q6040-6044 KTB1369-Y OR 2SA1930
Q6050-6054 MN100S-Y,P,O OR KTD1047-Y,O
Q6060-6064 MP100P-Y,P,O OR KTB817-Y,O
Q6070-6074 KTC3200-BL,GR OR 2SC1775A-E,F OR 2SC1845-E,F
Q6601-6603,Q6901 KTC3199-GR,2SC1740S-R,S,2SC2458-GR
Q6701,6702 KTC3200-BL,GR OR 2SC1775A-E,F OR 2SC1845-E,F
Q6703 KTA1268-GR,BL OR 2SA992-E,F
Q6303
KTA1267-GR OR 2SA933S-R,S
TYPE F6901,6902
D 8A/125V
P T8AL250V
G T8AL250V
J 8A/125V
W
T8AL250V
SR
SL
NONE
NONE
NAAF-7417
TX-SR500/E
SCHEMATIC DIAGRAM 5-1 ޓPOWER AMPLIFIER SECTION 3
U17
A
1
2
3
4
5
BCD
15
