Onkyo TX-SR805 User Manual

91
Advanced Setup —Continued
Equalizer Settings
With the Equalizer settings, you can adjust the tone of
speakers individually with a 7-band equalizer. The vol-
ume of each speaker can be set on page 90.
1
Press the [RECEIVER] REMOTE
MODE button, followed by the
[SETUP] button.
The main menu appears onscreen.
2
Use the Up and Down [ ]/[ ]
buttons to select “2. Speaker
Setup,” and then press [ENTER].
The Speaker Setup menu appears.
3
Use the Up and Down [ ]/[ ]
buttons to select “5. Equalizer
Settings,” and then press
[ENTER].
The Equalizer Settings screen appears.
These settings are set automatically by the Automatic
Speaker Setup function (see page 55).
RECEIVER
S
E
T
U
P
ENTER
ENTER
2.Speaker Setup
1.Speaker Settings
2.Speaker Config
3.Speaker Distance
4.Level Calibration
5.Equalizer Settings
6.THX Audio Setup
ENTER
ENTER
2-5.Equalizer Settings
Equalizer Manual
Channel Front
63Hz 0dB
160Hz 0dB
400Hz 0dB
1000Hz 0dB
2500Hz 0dB
6300Hz 0dB
16000Hz 0dB
4
Use the Left and Right [ ]/[ ]
buttons to set the “Equalizer”
option to:
Off: Equalizer off, flat response.
Manual: The equalizer for each
speaker can be set manually.
Audyssey: The equalizer for each
speaker is set automatically
by the Automatic Speaker
Setup function.
If you selected Manual, continue with
the next step. If you selected Off or
Audyssey, go to step 8.
5
Use the Down [ ] button to
select “Channel,” and then use
the Left and Right [ ]/[ ] but-
tons to select the speaker.
You can select: Front, Center, Sur-
round, Surr Back, or Subwoofer.
6
Use the Up and Down [ ]/[ ]
buttons to select a frequency,
and use the Left and Right
[ ]/[ ] buttons to cut or boost
that frequency.
You can select: 63 Hz, 160 Hz, 400 Hz,
1000 Hz, 2500 Hz, 6300 Hz, or
16000 Hz. And for the subwoofer,
25 Hz, 40 Hz, 63 Hz, 100 Hz, or
160 Hz.
Each band can be cut or boosted from
–6 dB to +6 dB in 1 dB steps.
Tip: Low frequencies, such as 160 Hz,
affect bass sounds; high frequencies,
such as 6300 Hz, affect treble sounds.
ENTER
ENTER
ENTER
ENTER
ENTER
TX-SR805875En.book Page 91 Thursday, April 26, 2007 3:00 PM

Onkyo TX-SR805 Specifications

General

Channels	7.1
HDMI Inputs	3
HDMI Outputs	1
Dolby Technologies	Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby TrueHD
DTS Technologies	DTS, DTS-ES, DTS 96/24, DTS-HD Master Audio
THX Certification	THX Select2
Component Video Inputs	3
Component Video Outputs	1
Composite Video Inputs	5
Composite Video Outputs	2
Digital Audio Inputs (Optical)	3
Digital Audio Inputs (Coaxial)	3
Digital Audio Outputs	1 (Optical)
Analog Audio Inputs	7
Analog Audio Outputs	2
Phono Input	Yes
Multi-room Output	Yes
Zone 2 Output	Yes
Preamp Outputs	7.1
Subwoofer Outputs	2
Remote Control	Yes
Frequency Response	5 Hz-100 kHz
Power Output per Channel	130 W (8 Ohm, 20 Hz-20 kHz, 0.05% THD, 2 channels driven)
THD	0.05%
Input Sensitivity	200mV
Signal-to-Noise Ratio	106 dB (Line), 80 dB (Phono)
Weight	50.7 lbs
