SHENZHEN ONTIME TECHNOLOGY CO.LTD
10
CNC INTERFACE
J1: connected to the CNC control system.
Terminal description:
J1-1: AUTO
Auto height control enable signal from CNC to AVC118
controller. Default definition: HIGH level signal enable
auto control, LOW level signal disable auto control. This
definition can be reversed by demand when placing order.
J1-2: UP
Torch UP signal from the CNC. Active level: LOW.
J1-3: DOWN
Torch DOWN signal from the CNC. Active level: LOW.
J1-4: START CUT
Start cutting cycle signal from the CNC, this signal must be
maintained during the entire plasma cutting cycle. Active
level: LOW.
J1-5: NC
J1-6: MOTION
Motion enable signal output to the CNC system. This signal
is issued after the plasma torch ignition and the pierce
process has been completed. This signal indicates that the
