LIFTER MOTOR AND LIMIT SWITCH
Lifter motor：
DC shunt motor, 24V DC, power within 60W.
Connected terminal: J2-5 and J2-6, if the torch up and down
direction is not corresponding to the controller, please
exchange the lead wires of the lifter motor.
Limit switch：
J2-1: Connect to the terminal of normal open contact of the
upper limit switch.
J2-2: Connect to the terminal of normal open contact of the
lower limit switch.
J2-3: Connect to the terminals of common contact of the upper
and lower limit switches.
PLASMA START
Terminal: J3-5 and J3-5. Relay contact output, 10A/250V.
Connect to the start arc terminal of the plasma power source.
