SHENZHEN ONTIME TECHNOLOGY CO.LTD
8
J4：Arc voltage input.
Through this lock terminal, Connect the WORK terminal
inside the controller to the positive terminal of plasma
power, and connect the E-TRODE terminal to the
negative terminal of the plasma power.
AVC118 has been integrated an isolated arc voltage
divider, the divided ratio is 1:100. The arc voltage sense
wires should be at least 0.9 mm squared twisted pair
wire, rated 600V or greater. When connecting arc
voltage sense wires to the controller, please check the
arc voltage polarity carefully to ensure correct
connection, otherwise serious damage may occur.
J5
：
SHIELD CAP.
Through this lock terminal, Connect the shield cap lead
line (as the Ohmic IHS sensing signal) to the SHELD
terminal.
