ontime AVC118 - Terminal Definitions; J1: CNC Controller Connection; J2: Power and Motor Connection; J3: Proximity and Start Signal Connection

SHENZHEN ONTIME TECHNOLOGY CO.LTD
7
TERMINALS DEFINITION
NAME TERMINAL SIGNAL FUNCTION
J1
1 AUTO CNC AUTO THC Enable
2 UP CNC Torch Up Signal
3 DOWN CNC Torch Down Signal
4 START CUT CNC Start Cutting Signal
5 NC
6 MOTION Motion Enable to CNC
7 NC
8 COM GND of Control Signals
9 NC
J2
1 UP_LMT Upper Limit Switch
2 DOWN_LMT Lower Limit Switch
3 COM GND of Control Signals
4 MOTOR_1 Motor Terminal 1
5 MOTOR_2 Motor Terminal 2
6 DC24V(+) Power Supply DC24V(+)
7
DC24V(-) Power Supply DC24V(-)
J3
1 PRO_VCC_12V+
Power of the Proximity
Switch :+12V
2 PRO_SW_SIGNAL Proximity Switch signal in
3 PRO_GND_0V
GND of the Proximity Switch
Power: 0V
4 PLASMA_START1 Plasma Start Switch Term.1
5 PLASMA_START2 Plasma Start Switch Term.2
