4. Feed the ribbon from
the Ribbon Supply
Shaft under the Print
Head
5. Wrap the ribbon
around the Ribbon
Shaft and stick the
ribbon onto the
Empty Ribbon Roll
Core.
6. Firmly close the
printing mechanism.
Note:
• On www.opal-etiketten.com you will find all informations to label and ribbon types. So you can
achieve, with the OD5+ printer, optimum print results.
