Opal OD5+ Series - Printer Parts

User Manual v.2.2
OD5+ Serie
OPAL – Your AutoID System Integrator
opal-holding.com
- 7 -
1.4 Printer Parts
1
Cover Open Button
2
Top Cover
3
Label Roll Core
4
Ribbon Rewind Wheel
5
Printing Mechanism
6
Ribbon Rewind Shaft
7
Locking Tenon (left/right)
8
Stripper
1
LED Light (Ready)
2
LED Light (Status)
3
FEED Key
4
Print Head Pressure
Adjustment Screw (left/right)
