1
Ribbon Supply Shaft
2
Label Guide
3
Platen Roller
4
Print Line Adjustment Gear
5
Label Sensor
1
Power Switch
2
Power Socket
3
USB Port
4
Serial Port
5
Ethernet Socket
6
Mini Parallel Port
7
FAN-FOLD LABEL INSERT
Feed slot for external label
feeding
4
5
1
3
2
