Opal OD5+ Series - Interfaces

User Manual v.2.2
OD5+ Serie
OPAL – Your AutoID System Integrator
opal-holding.com
- 31 -
Model Name
OD5+
OD5+300
Dimension
Length: 285mm (11.2”) / Height:171mm (6.8”) / Width:226mm (8.9”)
Weight
2.72 kg
Note:
• Specifications are subject to change without notice. All company and/or product names
are trademarks and/or registered trademarks of their respective owners.
5.2 Interfaces
Parallel Interface
PIN Nr.
FUNCTION
TRANSMITTER
1
2-9
10
11
12
13
14
15
16
17
18
19-30
31
32
33
34-35
36
/Strobe
Data 0-7
/Acknowledge
Busy
/Paper end
/Select
/Auto-Linefeed
N/C
Signal ground
Chassis ground
+5V,max 500mA
Signal ground
/Initialize
/Trouble message
Signal ground
N/C
/Select-in
PC / Printer
PC
Printer
Printer
Printer
Printer
PC / Printer
PC
PC / Printer
Printer
PC / Printer
Serial Interface
Standard Settings: 9600 Baud Rate, no Parity, 8 Data Bits, 1 Stop Bit, XON/XOFF
DB9
SOCKET
DB9 PLUG
---
1 1
+5V,max
500mA
RXD
2 2
TXD
TXD
3 3
RXD
DTR
4 4
DSR
GND
5 5
GND
DSR
6 6
DTR
RTS
7 7
N/C
CTS
8 8
RTS
RI
9 9
N/C
PC
Printer
The total current output from parallel port and serial port all together can’t exceed 500mA.
USB Interface
Connector type: Type B
PIN NO.
1
2
3
4
Function
VBUS
D
-
D
+
GN
D
