6. Peel off the first label,
and feed the liner
through the roller and
the Tear-off Bar.
7. Follow the direction as
shown in figure to feed
the liner across the
stripper.
8. Close the printing
mechanism and the
stripper.
9. Press the FEED key to
adjust the position of
label and complete the
installation.
Notes:
• Label liner thickness is recommended to be 0.06mm ± 10% with basic weight 65g/ ㎡ ± 6%.
• The label / paper used for stripper are suggested to be at least 25mm in height.
• The max label width for stripper is 110mm.
.
