214 Self-help, vehicle care
Picture no: 18130s.tif
Main beam
1. Open bonnet and engage support.
2. Rotate headlamp cap anticlockwise and
remove.
3. Detach plug connector from bulb.
Picture no: 18132s.tif
4. Disengage spring wire clip from retaining
lugs by moving it and swivelling it to the
side.
5. Remove bulb from reflector housing.
6. When fitting the new bulb, insert lugs in
the reflector recesses.
Picture no: 18133s.tif
7. Engage spring wire clip, plug connector
onto bulb.
8. Fit headlamp cap and rotate clockwise.
