224 Self-help, vehicle care
Picture no: 18263s.tif
4. Detach bulb housing towards the rear.
Picture no: 18384s.tif
5. Gently press the three locking lugs on the
outside of the bulb holder outwards and
remove bulb holder.
Picture no: 18387s.tif
Bulbs in bulb carrier
6. Remove bulb from holder, gently
pressing the bulb and rotating it.
7. Insert new bulb, pressing it gently and
rotating it.
8. Engage bulb holder in bulb housing,
ensuring that it properly engages.
1 = Reversing lamp (right side), rear
fog lamp (left side)
2 = Tail lamp
3 = Turn signal lamp
4 = Tail lamp/brake lamp
5 = Tail lamp
