223Self-help, vehicle care
Picture no: 17289t.tif
10. Insert bulb housing in vehicle body,
engaging the ratchet and bolt in
recesses. Tighten attachment nuts by
hand. Engage plug connector. Close
cover.
11. Carry out the following steps to ensure
proper function of the tail lamps:
Picture no: 18261s.tif
3-door passenger vehicle, van
1. Disengage right and left cover in the side
luggage compartment trim, then open.
Picture no: 18262s.tif
2. Remove plug connector by pressing on
bulb holder tab.
3. Hold bulb housing from the outside;
unscrew two retaining nuts.
– Switch on ignition
– Operate brake
– Switch on parking lamps
