2.5 Milling table
Table length [mm] 700
Table width [mm] 180
Max. bearing load 50 kg
T-slot size/distance/number 12 / 63 / 3
X axis travel [mm] 480
Y axis travel [mm] 175
2.6 Dimensions
 Fastening to the Machine Base on page 24
Total weight [kg] 116
2.7 Work area
Keep a work area of at least one metre around the
machine free for operation and maintenance.
2.8 Speeds
Electronic speed range / Gear stages [ rpm ]
at 230V +- 1%
90 - 3000 / 2 ( ~ 50 Hz )
2.9 Environmental conditions
Temperature 5 - 35 °C
Admissible relative humidity 25-80%
Environmental conditions - storage -5°~45°
2.10 Operating material
A-A
A
A
674
12
63
180
