Optimus MD-30C - Technical Characteristics; Software and Firmware Versions; Document Version Tracking

MD-30C version 3.2.000
13
Microphone desk
with CAN bus connection
MD-30C
10. TECHNICAL CHARACTERISTICS
MD-30C
Inputs 1 Input, through RJ45 connector
Outputs 1 Output, through RJ45 connector
Power supply 24 VDC
Consumption 150 mA
Weight 1.7 kg
Finishes Desk: RAL7021 Bayblend plastic
Flexo MICROPHONE
Capsule Dyna mic
Polar diagram Unidirectional
Frequency response
150 Hz ∼12 kHz
Sensitivity 2.2mV/Pa/1kHz
Output impedance
500 Ohm ± 30% (at 1kHz)
Material Aluminium
11. SOFTWARE AND FIRMWARE VERSIONS
The functionalities described in this user manual are valid for software and firmware versions that are the same or later versions of:
MD-30C Firmware Ve rsion 5.11
COMPACT Firmware Application version 3.2
Linux version 2.6.35.14
Call Point Software Vers ion 3.2
12. DOCUMENT VERSION TRACKING
Reference system Type of Document Confidentiality N/A
COMPACT/MD-30C Installation and operation guide
Rev Date Modifications Content Written by:
3.1.000
Ma rch 2017
Translation of the Spanish language version 3.1.000
R+D Department
3.2.000 October 2018
5.2. Audio and CAN bus connection.
11. Softwa re and firmware versions.
R+D Department
Approved by Function Date
Fe rra n Gironès i Puig R+D Director
10/2018
