EDFA optical amplifier – user manual
28
MODE
Choice of actual mode
OFF mode
AGC mode
APC mode
LI
Threshold value for Loss input alarm
AGC
Setting APC mode / Set constant output power
APC
Setting AGC mode / Set constant gain
LO
Threshold value for Loss output alarm
Table 7 - Normal mode - adjustable values
For accept your changes must click to button “Update module”
NOTE: if optical output level is higher than +10dBm is displayed by EDFA unit
logo “!DANGER!”. This is only warning report about high optical output level.
Picture 9 – DANGER report
