11 Display
Main menu
The Main menu contains basic items according this screenshot. The user can
choose each item via buttons UP/DOWN. For enter to item use the middle button
(character “O”)
Ma i n me n u
Over vi ew
He a l t h
Al ar ms
Parameters
Settings
Scr eensaver
Hel p and About
Main menu -> Overview
Overview menu contains only report about the basic EDFA status.
EDFA 1
MODE : 0
TEMPER : 25.2C
EDFA 1 S1 - Pr eamp 16dB
AGC : 20.00dB
APC : 15.00dBm
POWER_I N : - 50. 00dBm
POWER_OUT: - 50. 00dBm
EDFA 1 means the first EDFA module inside the CLA
EDFA 2 means the second EDFA module inside the CLA
EDFA 1 S1 means the first stage in EDFA 1 (Pre-amp or Booster)
EDFA 1 S2 means the second stage in EDFA 1 (Pre-amp or Booster)
Example:
CLA PB01F
EDFA 1 S1 – Pre-amplifier
EDFA 1 S2 – Booster amplifier
CLA PB02F
EDFA 1 S1 – Pre-amplifier
EDFA 2 S1 – Booster amplifier
Main menu -> Health
Item Health contains same information as in Bios of PC (Voltage status on the
power supply units, temperatures, fan speed)
