OPTOKON EDFA - Main menu -> Settings -> EDFA settings -> EDFA 1; Main menu -> Settings -> EDFA settings -> EDFA 1 S1 (Standard mode)

EDFA optical amplifier – user manual
46
EDFA s et t i ngs
EDFA 1
EDFA 1 S1 - Pr eamp 16dB
EDFA 1 S2 - Boost er 20dB
Change t o exper t mode
Main menu -> Settings -> EDFA settings -> EDFA 1
User can set actual the EDFA working mode.
Setting EDFA 1
MOD E
Oper at i on mode of EDFA modul e
OF F
APC ( Aut omat i c power cont r ol )
AGC ( Aut omat i c gai n cont r ol )
The ACC mode is via the Display module denied.
The information about working mode in Chapter 12 - Table 13
Main menu -> Settings -> EDFA settings -> EDFA 1 S1 (Standard mode)
User can change settings of working mode and threshold for Loss IN or OUT alarm.
Set t i ng EDFA 1 - st age 1
APC
AGC
LI
LO
For editing the values use the Display module keyboard.
For changing of the position use buttons LEFT/FIGHT
For character browsing use buttons UP/DOWN
