EDFA optical amplifier – user manual
43
Vol t ages
VOLT_R05V: 5. 05V
VOLT_R12V: 11. 98V
VOLT_L05V: 5. 02V
VOLT_L12V: 11. 98V
Temper at ur es
TEMP_CHI P: 29. 00C
Fan r ounds
VOLT_L12V: 11. 98V
Temper at ur es
TEMP_CHI P: 29. 00C
Fan r ounds
FAN_FAN1 : 6452RPM
FAN_FAN2 : 6683RPM
FAM_FAN3 : 4415RPM
FAN_FAN4 : 0RPM
Main menu -> Alarms
Item Alarms contains report about alerts on the EDFA units. Alarms see in
chapter 13.
Al er t s
EDFA 1 S1 - Pr eamp 16dB
INLOS
OUT L OS
EDFA 1 S2 - Boost er 20dB
INLOS
OUT L OS
If don`t exist alarms, the display screen information “No alarms found”.
No al ar ms f ound.
Main menu -> Parameters
Item Parameters enable see technical and optical parameters of the EDFA units.
