EDFA optical amplifier – user manual
45
Vi ew EDFA 1 - st age 1
ACC : 0.0mA
AGC : 20.0dB
ALSFNC : E
ALSVAL : -10.0dBm
APC : 15.0dBm¨
GAIN : -27.0dB
Vi ew EDFA 1 - st age 1
TEC_ 1 _ CURRENT : 2 5 . 3 mA
LD_1_CURRENT : 0. 6mA
LI : -30.0dBm
LO : -10.0dBm
PLD_ 1 _ POWER : 0mW
PDL_1_TEMP : 24.9C
Vi ew EDFA 1 - st age 1
POWER_IN : -50.0dBm
POWER_OUT : -50.0dBm
POWER_MAX : 16.0dBm
GAIN_MAX : 35.0dB
CURRENT_MAX : 280. 0mA
Items are described in Chapter 9.4 - Table 8.
Main menu -> Settings
Item Settings enables change of the EDFA optical parameters, Network
parameters and change of display password.
Settings menu
EDFA settings
Net wor k set t i ngs
Set di spl ay passwor d
Main menu -> Settings -> EDFA settings
This item enables change of the EDFA optical parameters.
