EDFA optical amplifier – user manual
47
For confirm of your changes use the middle button
Example:
Type i n AGC i n dB:
20.
Gai n val ue set i n AGC mode
0
Main menu -> Settings -> EDFA settings -> Expert / Standard mode
This item enables change of level settings for the EDFA unit. The standard
mode enables only basic settings. The expert mode enables settings all available
parameters.
Example by EDFA 1 S1 (Expert mode):
Set t i ng EDFA 1 - st age 1
ACC
AGC
ALSFNC
ALSVAL
APC
Set t i ng EDFA 1 - st age 1
LI
LO
POWER_ MAX
GAI N_ MAX
CURRENT _ MAX
Main menu -> Settings -> Network settings
In this part user can change of Network settings.
Net wor k set t i ngs
I P addr ess
Net wor k mask
Default gateway
Rest ar t net wor ki ng
I CMP pi ng
For editing the values use the Display module keyboard.
