EDFA optical amplifier – user manual
56
Example usage:
LO{sp}1{sp}10{cr}
Set LO alarm threshold stage 1 to 10 dBm
Reply is:
LO{sp}1{sp}10{cr}
Example usage:
LO{sp}2{sp}20{cr}
Set LO alarm threshold stage 2 to 20.0 dBm
Reply is:
LO{sp}2{sp}20{cr}
LO{cr} Get Loss of Output Power Signal alarm threshold for each stage
Example usage:
LO{cr}
Get the value of the Loss of Output Power Signal alarm threshold.
Reply is:
LO{sp}1:{sp}10.0{sp}dBm{cr}
LO{sp}2:{sp}20.0{sp}dBm{cr}
Indicating that LO stage 1 =10 dBm and LO stage 2 =20 dBm
LP{sp}[1,2,A]{cr} Get Pump Laser Output Power
Example usage:
LP{sp}1{cr}
Reports pump laser output power for pump laser diode 1.
Reply is:
LASER1:{sp}180.4{sp}mW{cr}
If the requested pump laser diode is not fitted into the EDFA module, then the
reply is:
FWC{cr}
LP{sp}A{cr}
Reports pump laser output power for all pump lasers.
Reply is:
ALL:{sp}100.5{sp}120.5{sp}mW{cr}
