Optoma ES520 - DMD and Color Wheel Specifications; Lamp and Connector Specifications

Delta Elec. Inc. ES520 & EX530 ver.02
Company Confidential Optoma___________________ Delta________________
8
2008/09/17
2-2.DMD Specifications
Unit Min. Max.
Typical Notes
DMD type (ES520) TI 0.55" SVGA 12 deg LVDS Type A
Dark chip 1
Number of Columns (ES520) Pixel
800
Number of Rows (ES520) Pixel
600
DMD type (EX530) TI 0.55" XGA 12 deg LVDS Type A Dark chip 2
Number of Columns (EX530) Pixel
1024
Number of Rows (EX530) Pixel
768
Panel Operating Temp.
℃
10 65
Ambient Temp
℃
25
2-3.Color Wheel
Spec.
Unit Min. Max.
Typical Notes
Color Segment
RYGWB 82/29/80/91/78 (44mm)
2-4. Lamp
Description
Vendor
OSRAM
Type
E20.6 180W
Standard Mode , 3000 Hours Standard @ 180W, 50% Survival Rate
Lamp Life
ECO Mode , 4000 Hours Typical @ 150W, 50% Survival Rate
Normal: 180W±3%@Vo from 50V to 120V
Lamp Power
ECO: 150W±3%@Vo from 50V to 120V
2-5. Input/output connectors
VGA in (Compatible with HDTV component YPbPr / SCART)
PC
USB (Service Only)
Composite video (RCAx1)
Video
S-Video (Mini-DIN)
RS232 DB9
Audio Input: R / L (RCA X 2) , Out: Mini-Jack X 1
Security Kensington slot
