Optoma HD72 - Adjusting Projector Height

Installation
English
15
Adjusting the Projected Image
Adjusting the Projector’s Height
Tilt-Adjustment Feet
Elevator Feet
The projector is equipped with elevator feet for adjusting the
image height.
To raise the image:
1. Press the elevator button .
2. Raise the image to the desired height angle , then release
the button to lock the elevator feet into position.
3. Use screw in feet  to fine-tune the display angle.
To lower the image:
1. Press the elevator button.
2. Lower the image, then release the button to lock the
elevator feet into position.
3. Use screw in feet  to fine-tune the display angle.
Elevator Button
2
1
3
