EN-21
Connecting an HDMI source device
Examine your Video source device to determine if it has a set of unused
HDMI output jacks available:
If so, you can continue with this procedure.
If not, you will need to reassess which method you can use to connect to
the device.
To connect the projector to an HDMI source device:
1. Take an HDMI cable and connect one end to the HDMI output jack of the
HDMI source device.
2. Connect the other end of the HDMI cable to the
HDMI
jack on the
projector.
Connecting a Component Video source device
Examine your Video source device to determine if it has a set of unused
Component Video output sockets available:
If so, you can continue with this procedure.
If not, you will need to reassess which method you can use to connect to
the device.
To connect the projector to a Component Video source device:
1. Take a VGA (D-Sub) to HDTV (RCA) cable and connect the end with 3
RCA type connectors to the Component Video output sockets of the
Video source device. Match the color of the plugs to the color of the
sockets; green to green, blue to blue, and red to red.
2. Connect the other end of the cable (with a D-Sub type connector) to the
VGA1/YPbPr
or
VGA2/YPbPr
socket on the projector.
Important
If the selected video image is not displayed after the projector is turned on and the
correct video source has been selected, check that the Video source device is turned on
and operating correctly. Also check that the signal cables have been connected
correctly.
