Appendix. Screw torque
item-S Screw Type P/N
S
crew Driver Torque (kg-cm
)
1 M2.5x0.45x6
3105142300
2.2~2.8
2 M2x0.4x4
31051473xx
1.7~2.3
3 M2x0.4x5.3
31052705xx
1.7~2.3
4 M2x0.4x5.3
31052705xx
1.7~2.3
5 HEX 4.7x4 F
34614317xx
2.7~3.3
6 M2x0.4x5.3
31052705xx
1.7~2.3
7 M2x0.4x4
31051473xx
1.7~2.3
8-1 M2x0.4x4
31051473xx
1.7~2.3
8-2 M2.5x0.45x6
3105142300
2.2~2.8
9 M2x0.4x25
31052703xx
1.7~2.3
10 M2x0.4x4
31051473xx
1.7~2.3
11 M2x0.4x4
31051473xx
1.7~2.3
12 M2.5x0.45x6
3105142300
2.2~2.8
13 M2.5x0.45x18.8
31053662xx
1.7~2.3
14 M3x0.5x5
31053108xx
4.3~5.5
15 M2x0.4x5.3
31052705xx
1.7~2.3
16 HEX 4.6x20
34614710xx
1.7~2.3
17 HEX 4.6x17
34614687xx
1.7~2.3
18 M2x0.4x4
31051473xx
1.7~2.3
19 M3x0.5x5
31001007xx
2.7~3.3
20 M2x0.4x5.3
31052705xx
1.7~2.3
21 M2x0.4x4
31051473xx
1.7~2.3
22 M2.5x0.45x6
31051423xx
2.2~2.8
23 M2x0.4x4
31051473xx
1.7~2.3
