INTRODUCTION
Connections
1 2 5 6 7 8 9 10 11 12
131415
43
No Item No Item
1.
USB Power OUT (5V 1.5A)
Connector
9. S/PDIF Connector
(only 2ch PCM supported)
2. VGA In Connector 10. 12V Out Connector
3.
USB Port
(WiFi dongle/Media Player)
11. Audio In Connector
4. RJ-45 Connector 12. Audio Out Connector
5. RS-232 Connector 13. Security Bar
6. HDMI 1 Connector
(4K 60Hz; for low latency gaming)
14. Kensington
TM
Lock Port
7. HDMI 2 Connector
(4K 60Hz; for PureMotion)
15. Power Socket
8. USB Port
(WiFi dongle/Media Player)
