Optoma UHD35x User Manual

English
42
USING THE PROJECTOR
System settings menu
On the Home screen, select the system settings menu “ ” to congure various system settings.
General menu navigation
Main Menu
Settings
Sub Menu
1. When system settings menu is displayed, use the up and down navigation buttons to select any item
in the main menu. While making a selection on a particular page, press the “OK” or the “Right” button
on the remote control to enter the submenu.
2. Press the “Left” and “Right” button to select the desired menu item. Then press “OK” to open its sub
menu.
3. Press the “Up” and “Down” button to select the desired item in the sub menu.
4. Press the “OK” or “Right” button to access the selected sub menu item settings.
5. Press the “Up”, “Down”, “Left”, or “Right” button to select the setting or press the “Left” and “Right”
button to adjust the value (if necessary).
6. Press “OK” to conrm the setting.
7. Select the next item to be adjusted in the sub menu and modify as described above.
8. To exit, press “ ” (repeatedly if necessary). The settings menu will close and the projector will
automatically save the new settings.

Optoma UHD35x Specifications

General

Product color	White
Product type	Standard throw projector
Market positioning	Home cinema
Native aspect ratio	16:9
Projection distance	1.21 - 9.9 m
Vertical scan range	24 - 120 Hz
Horizontal scan range	31 - 135 kHz
Projection technology	DLP
Supported aspect ratios	3:4, 16:9
Contrast ratio (typical)	1000000:1
Screen size compatibility	33 - 300 \
Projector native resolution	2160p (3840x2160)
Keystone correction, horizontal	-40 - 40 °
RMS rated power	10 W
Number of built-in speakers	1
Built-in display	No
Lamp power	240 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	10000 h
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	305 W
Power consumption (standby)	0.5 W
Offset	105 %
Focal length range	15.84 - 17.42 mm
Supported 3D formats	Frame packing
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
Noise level	28 dB
Number of OSD languages	10
Noise level (economic mode)	26 dB
On Screen Display (OSD) languages	CHI (SIMPL), DEU, ENG, ESP, FRE, ITA, JPN, POR, RUS

Weight and Dimensions

Depth	270 mm
Width	315 mm
Height	118 mm
Weight	3980 g
