Soft key indicators:
Position
Indicator
Purpose
Left soft key
To power on the device
To power off the device, with long press
Right soft key
Open menu with long press
LED indicators:
The recharging and connection to PC is indicated with green (charging) and blue (connection) LED-lights:
Position
Indicator
Purpose
Left LED-indicator
Green
Active when device is powered on, blinking when charging in
cradle.
Right LED-indicator Blue
Active when devices is placed to the cradle and connected to a
PC.
Graphical indicators:
These indicators are displayed on the top row of the display during imaging:
