Power frequency
(50/60 Hz) magnetic
field
IEC 61000-4-8
Power frequency magnetic fields should
be at levels characteristic of a typical
location in a typical commercial or
hospital environment.
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
&
6 Vrms
ISM frequency
3 Vrms
150 kHz to 80 MHz
&
6 Vrms
ISM frequency
Portable and mobile RF communications
equipment should be used no closer to
any part of Smartscope M5, including
cables, than the recommended separation
distance calculated from the equation
applicable to the frequency of the
transmitter.
Recommended separation distance
d = 1.2
√
𝑃
d = 1.2
√
𝑃 80 MHz to 800 MHz
d = 2.3
√
𝑃 800 MHz to 2.7 GHz,
where P is the maximum output power
rating of the transmitter in watts (W)
according to the transmitter manufacturer
and d is the recommended separation
distance in meters (m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic site
survey
A
, should be less than the
compliance level in each frequency
range
B
.
Interference may occur in the vicinity of
equipment marked with the following
symbol:
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2.7 GHz
AM Modulation
&
9–28 V/m
385 MHz to 6.0 GHz
Pulse Modulation
3 V/m
80 MHz to 2.7 GHz
AM Modulation
&
9–28 V/m
385 MHz to 6.0 GHz
Pulse Modulation
NOTE 1: U
T
is the AC mains voltage prior to application of the test level
NOTE 2: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 3: The ISM (industrial, scientific and medical) bands between 0.15 MHz and 80 MHz are 6.765–6.795 MHz;
13.553–13.567 MHz; 26.957–27.283 MHz and 40.66–40.70 MHz.
NOTE 4: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
A) Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with
accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey
should be considered. If the measured field strength in the location in which the Smartscope M5 is used exceeds
the applicable RF compliance level above, Smartscope M5 should be observed to verify normal operation. If
abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the
Smartscope M5.
B) Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
