DRAFT
Proprietary and Confidential
Acme Packet 1100 Hardware Installation Guide 19
4 System Installation
Introduction
This chapter provides information about how to install the Acme Packet 1100 and its
associated components, includes cabling information.
Shipped Parts
Each Acme Packet 1100 ships in one box. Inside this box is the Acme Packet 1100
chassis, accessory kit and options. The following table lists the contents of one Acme
Packet 1100 order.
Table 4 - 1. Acme Packet 1100 Shipping Contents
Installation Tools
and Parts
The following tools and parts are required to cable and install the Acme Packet 1100
into your equipment rack or mount the chassis on a wall:
• #2 Phillips-head screwd
river
• Rack and associated mounting hardware
• Shielded Ethernet CAT5e or CAT6 RJ45 cables (EXT/INT/NET MGT ports)
• RS-232CF cable with RJ45 jack (SER MGT port)
• Phone cable with RJ45 jack (T1/E1 port)
Recommended
Tools and Parts
Acme Packet recommends that you have the following parts on hand:
• Cable labels
• UPS
• ESD wr
ist or heel straps
• ESD-safe location
Location Item
Main Shipping Box Acme Packet 1100 chassis
Accessory Kit - AC Power Cord
- AC Power Supply
Options - Flanges for Rack Mounting
- Brackets for Wall Mounting
