Table 7 - 6. Acme Packet 1100 Environmental Specifications
SPECIFICATIONS
Acme Packet 1100 Hardware Installation Guide 51
Connector Specifications
Refer to the following table for information about the connector specifications for the
Acme Packet 1100.
Table 7 - 7. Acme Packet 1100 Connector Specifications
Specification Description
Temperature The Acme Packet 1100 is required to operate within the
temperature range of:
32° F to 104° F (+0° C to +40° C) (operating)
-4° F to 149° F (-20° C to +65° C) (storage)
Relative Humidity 10% to 85%, non-condensing
Maximum Altitude The Acme Packet 1100 System is required to operate below the
maximum altitude of 10,000 feet.
Air Flow Single fan: 2.2 CFM (3.6 CFM Max)
Dual fans: 3.6 CFM (7.2 CFM Max)
Power Dissipation 10 Watts (maximum)
Specification Description
RJ45/Management Ethernet
Ports
The 3 x 8-pin RJ45 10/100 Ethernet ports are compliant with
IEEE's 802.3, 802.3u, 802.1q and 802.3ab.
RS232/Serial Port The RS232 serial port uses an 8-pin RJ45 connector that supports
the RS232-C protocol.
IEC Connector Ports The IEC connector ports accept a 3-lead IEC-320 connector for AC
power installations.
