DRAFT
Proprietary and Confidential
42 Acme Packet 1100 Hardware Installation Guide
MAINTENANCE INTRODUCTION
4. Remove the screws that secure the Acme Packet 1100 to the equipment rack or
wall mount. Reference the System Installation chapter for more information.
5. Pull the Acme Packet 1100 forward and out
of the equipment rack.
6. Lift the Acme Packet 1100 out of the equipme
nt rack, and move it to an ESD-
safe location.
Removing and Installing the Chassis Cover
The following subsections describe how to remove the cover of the Acme Packet
1100 to provide access to the internal components of the chassis. Once the unit
is powered down, the chassis cover can be removed to provide access to the
inside of the chassis for service access to replaceable components.
Caution Only authorized personnel should remove or install the
chassis cover of the Acme Packet 1100! Damage to the
equpment can result if the procedures described in these
subsections are performed by unauthorized personnel!
Caution Never remove or install the chassis cover or access the
internal components of the Acme Packet 1100 unless the
power cord is unplugged!
Chassis Cover
Installation and
Removal
Guidelines
Please read and follow these pre-installation guidelines prior to either
installing or removing the cover of the Acme Packet 1100:
• G
round yourself and follow proper ESD grounding procedures.
• Install or remove the chassis cover only according to the procedure
described in the subsections below.
• The installation and removal procedures should be performed during low-
traffic periods or during times of scheduled maintenance.
• Follow industry-standard procedures to ensure ESD protection.
• When installing or removing the Acme Packet 1100, move the chassis to an
ESD-safe location.
Required
Parts/Tools
The following parts are required to install or remove the cover of the Acme
Packet 1100 chassis:
• ESD wri
st strap
• ESD safe location
• Phillips head screwdriver
