Acme Packet 1100 Hardware Installation Guide 47
7 Specifications
Introduction
This chapter provides information regarding the specifications and regulatory
certifications of the Acme Packet 1100.
Acme Packet 1100
System
Specifications
Table 7 - 1. Acme Packet 1100 System Specifications
Chassis Mounting
Flanges Physical
Specifications
(Optional)
Table 7 - 2. Chassis Mounting Flange Physical Dimensions
Specification Description
Height 1.75 in (4.45 cm) (1U)
Width 11.25 in (28.57 cm)
Depth 8.48 in (21.54 cm)
Weight 4.0 lbs (1.81 kg)
Ports • Four 10/100 Mbps Ethernet copper ports (RJ-45 connector) dedicated
to WAN, LAN, management and reserved functions
• One T1/E1 port for PSTN fallback
Onboard Transcoding
& QoS Measurement
Module
• Hardware-assisted transcoding and QoS monitoring and reporting
Mounting • Table top
• Rack mount flanges for front/rear/center installation in 19/23 in
racks (optional)
• Wall mount brackets (optional)
LEDs • Front: Ethernet link and activity status LEDs for PWR, NET MGT, INT,
EXT, and OK
• Rear: Ethernet link and activity status LEDs for NET MGT, INT, EXT, and
T1/E1 link status
Memory • 4 GB for active configuration and logs
• 40 GB fast M-SATA drive for runtime image, backup configurations
and local CDR backup
System Reset Reset pinhole
Specification Description
Width 3.875 in (9.8425 cm) (each)
